Iron Worker
$1.00
| Model | Hydraulic Punching, Universal Hydraulic Iron Worker |
|---|
Related products
-
C Type Power Press
We deal in a wide range of Power Presses. They are either Mechanical Power Presses or even Pneumatic Power Presses. The Power Press Machines are available as C type Power Press and Pillar type Power Press. We have both Ungeared Power Presses as well as Geared Power Presses in various capacities.
MODEL 10 TON 20 TON 30 TON 50 TON 75 TON 100 TON 150 TON Measurement mm mm mm mm mm mm mm Bed Size 310x457 381x457 410x669 510x762 565x813 609x914 711x970 Bed to Ram 250 280 330 381 432 455 565 Stroke Length 52 63 75 95 110 115 127 Crank shaft Dia 80 90 100 110 125 152 185 Gear Dia. 455 558 609 711 813 863 1070 Fly Wheel Dia. 535 609 660 812 914 990 1070 Hole in Ram For Clamping 25 28 32 39 45 52 58 Motor R.P.M 1440 1440 1440 1440 1440 1440 1440 Power Requirement in H.P. 2 2 3 5 7.5 10 15 -
H Type Power Press
We deal in a wide range of Power Presses. They are either Mechanical Power Presses or even Pneumatic Power Presses. The Power Press Machines are available as C type Power Press, Inclinable Power Press and also Pillar type Power Press. We have both Ungeared Power Presses as well as Geared Power Presses in various capacities.
MODEL 30 TON 50 TON 75 TON 100 TON 150 TON 200 TON 250 TON MEASUREMENT mm mm mm mm mm mm mm BED SIZE 410x460 460x510 522x575 609x660 660x711 765x820 765x820 BED TO RAM 330 381 406 455 483 533 560 STROKE LENGTH 83 90 110 115 127 140 152 CRANK SHAFT DIA 100 100 125 152 185 204 230 GEAR DIA 609 711 813 863 1070 1270 1326 HOLE IN RAM FOR CLAMPING 32 39 45 52 58 56 63 NO. OF STROKES/MIN 45 45 40 40 30 30 30 MOTOR R.P.M. 1440 1440 1440 1440 1440 1440 1440 POWER REQUIREMENT IN H.P. 3 5 7.5 10 15 15 20 -
HYDRAULIC SHEARING MACHINE
Ultra-Heavy Frame Structure
The “HSVR” models are designed with a fully welded boxed-in bed table structure. The special worktable structure designed from limit element optimization make the curving SK, which is formed during shearing, to be able to compensate the curving of upper beam under the acting of shearing force, assuring the blade gap to keep same along the full length of worktable, enhancing the shearing precision and quality.
